8.6 Inch Stretched Bar LCD Display 600×1600 Driver IC JD9365DA-H3 TFT LCD Module

Product Categories
HuaXin Technology CO.,LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

8.6 Inch Stretched Bar LCD Display 600×1600 Driver IC JD9365DA-H3 TFT LCD Module

  • 1
  • 2
  • 3

Brand Name : HuaXin

Model Number : HX086IPW9032ANT

Certification : ISO14001/ ISO9001/IATF16949

Place of Origin : China

MOQ : 1~1000

Price : $40~$60

Payment Terms : T/T

Supply Ability : 500K pcs per month

Delivery Time : 4~6weeks

Packaging Details : blister+foam box+bubble bag+inside carton+master carton

Display Technology : bar type tft LCD

Display size : 8.6 inch tft

Resolution : 600*1600

interface : MIPI-4lane

View angle : all

Driver IC : JD9365DA-H3

Contact Now

8.6 Inch 600*1600 Stretched LCD Display with JD9365DA-H3 IC
8.6-inch industrial stretched TFT LCD display features 600×1600 high resolution and is equipped with the professional JD9365DA-H3 driver IC. Specially designed for long-strip display applications, it delivers stable performance and strong compatibility, making it an ideal display solution for industrial equipment, automotive displays, commercial showcases, stretched advertising screens and more.
Key Specifications:
Part No. HX086IPW9032ANT
Panel Size 8,6 inch TFT
Display Area (mm) 76.356(H)x203.616(V)
Module outline dimension 82.18(H)*212.85(V)*2.6(D)
Number of Dots 600*1600
View Angle ALL
Interface Pins MIPI-4lane
Contrast Ratio 1000
Working Temperature -20~70°C
Storage Temperature -20~70°C
Technical Drawing

TFT Product Knowledge

8.6 Inch Stretched Bar LCD Display 600×1600 Driver IC JD9365DA-H3 TFT LCD Module
TFT Structure
8.6 Inch Stretched Bar LCD Display 600×1600 Driver IC JD9365DA-H3 TFT LCD Module
Our advantage
  • Founded in 2009 in Hubei Enshi, specializing in LCD, LCM, TFT, backlight, and OLED research, development, and production.Product range includes VA, TN, HTN, STN, FSTN, CSTN LCDs and COB, TBA, COG, TP, LED backlight LCMs.
  • Registered capital: 20 million | Staff: 500+ (10% R&D, 15% QC)

  • Certifications: ISO14001, ISO9001/IATF16949, SGS

  • Cost-effective production base located in inland city

    •Advanced equipment ensuring stable quality

    • Highly automated processes for efficiency and consistency

    • Experienced engineering team with 20+ years in LCD field

    •Custom product design capabilities

Product Applications
  • Car navigation & printer
  • Video call & advertising
  • Automotive & medical devices
  • Fitness equipment & handheld devices
  • Industrial control and home appliance

8.6 Inch Stretched Bar LCD Display 600×1600 Driver IC JD9365DA-H3 TFT LCD Module
